IP Video Intercom Android Monitor SCP3044A-BZ, 10.1”, Black, Dahua

Intercoms

Product reference: VMSCP3044A-BZ

Android 14 with 4 GB RAM and 16 GB ROM, ensuring smooth performance and a user-friendly experience

Sleek full-screen design with an ultra-narrow black bezel - modern and minimalist look

The 10.1-inch IPS capacitive touchscreen with multi-touch supports up to 80° viewing angles both horizontally and vertically, improving usability and efficiency

Supports multiple communication modes including IP, Wi-Fi, and IP four-wire systems

Multi-color indicators with a breathing light function keep you informed of status changes

The screen wakes automatically when a person approaches for a seamless experience

A built-in light sensor automatically adjusts screen brightness for comfortable viewing

Integrated temperature and humidity sensors allow real-time monitoring

At stores prices may vary

Price:

€786.50

€650.00 tax excl.

Favourite

We have 4 qty.
Delivery in 1-2 business days

Product information

IP Video Intercom Android Monitor SCP3044A-BZ, 10.1”, Black, Dahua

Functions
Smart control panel with video intercom, video surveillance and wireless alarm functions. The Android 14 system supports APK installation, allowing expansion with third-party applications.

Application
Ideal for villas, residential communities, apartments, hotels, and office environments.

The device runs on Android 14, ensuring high performance and a user-friendly experience.
Its sleek full-screen design with an ultra-narrow black bezel delivers a modern and minimalist look.
The 10.1-inch IPS capacitive touchscreen with multi-touch supports up to 80° viewing angles both horizontally and vertically, improving usability and efficiency.
It supports multiple communication modes including IP, Wi-Fi, and IP four-wire systems.
Multi-color indicators with a breathing light function keep you informed of status changes.
The screen wakes automatically when a person approaches for a seamless experience.
A built-in light sensor automatically adjusts screen brightness for comfortable viewing.
Integrated temperature and humidity sensors allow real-time monitoring of indoor conditions directly from the home screen.

System

Main Processor

Embedded Processor

Operating System

Android 14

Network Protocol

IPv4;RTSP;UDP;DNS;FTP;RTP;TCP;SIP

Basic

Screen Type

Capacitive Touchscreen

Display Screen

10.1-inch display screen

Screen Resolution

1280 (H) × 800 (V)

Audio Compression

G.711a; G.711u; PCM

Audio Input

1 channel

Audio Output

Built-in speaker

Audio Mode

Two-way audio

Audio Enhancement

Echo suppression/digital noise reduction

Audio Bit Rate

16 kHz, 16 bit

Function

Communication Mode

Full digital;Analog 4-wire

Information Release

Receive and view the published information from the management center

Elevator Control

Residents can call the elevator through this device to their floor.

Leave Videos

Yes (SD card is inserted in the indoor monitor or door station)

DND Mode

Do not disturb period can be set

Number of Extensions

Villa: 1 main VTH and 9 extensions
Apartment: 1 main VTH and 4 extensions

Storage

Supports micro SD card storage (up to 512 GB)

Network

Wi-Fi

Yes

Wireless Standard

IEEE 802.11a/b/g/n/ac/ax

Wireless Frequency Range

2.4 GHz; 5 GHz

Max. Transmission Power

≤ 20 dBm @ 2400-2483.5 MHz

Bluetooth

Wireless Standard

BR/EDR/BLE

Wireless Frequency Range

2400-2483.5 MHz

Max. Transmission Power

≤ 20 dBm @ 2400-2483.5 MHz

Bluetooth

Yes

Zigbee

Wireless Standard

802.15.4

Wireless Frequency Range

2400-2483.5 MHz

Max. Transmission Power

≤ 10 dBm @ 2400-2483.5 MHz

Zigbee

Zigbee 3.0: Reserved to realize third-party access.

Sub 1G

Wireless Frequency Range

868-868.6 MHz

Max. Transmission Power

14 dBm @ 868-868.6 MHz

Modulation Method

FSK/GFSK

Port

RS-485

USB

Alarm Input

8 channels

Alarm Output

1 channel

Power Output

1 port (12 V, 200 mA)

Doorbell

Yes (use the alarm input port)

Network Port

1 × 10/100 Mbps Ethernet port

4-wire

Performance

Casing Material

PC + ABS

General

Appearance Color

Gray

Power Supply

12 VDC, 2 A
Standard PoE

Power Adapter

Optional

Installation

Flush Mount

Certifications

Accessory

Included: RS-485, power output cable, bracket, alarm cable, and analog cable.
Optional: Power cord

Product Dimensions

246.5 mm × 156.1 mm × 33.0 mm (9.70" × 6.15" × 1.30") (H × W × D)

Operating Temperature

-10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

10%–95% (RH), non-condensing

Operating Altitude

Below 3,000 m (9,842.52 ft)

Power Consumption

≤ 12 W (standby), ≤ 15 W (working)

Gross Weight

1,590 g (3.51 lb)

Storage Temperature

0 °C to +40 °C (+32 °F to +104 °F)

Storage Humidity

30%–75%

Operating Environment

Indoor
