KeyPad Plus Wireless touch keypad with card reader, DESFire

Product information

Contactless control without reliability compromises

KeyPad Plus is a combination of design, advanced encryption technology, and elaborated user experience for the most straightforward and protected security management. Arm and disarm Ajax, activate Night Mode and manage specific groups with a Pass card or Tag key fob.

Top-tier data protection

To identify users quickly and securely, KeyPad Plus features the DESFire® technology. It is the best-in-class contactless solution to identify a user by card or key fob.

DESFire® is based on the ISO 14443 international standard and combines comprehensive 128-bit encryption and copy protection. This technology is also used in transportation systems of European capitals and access systems at NASA.

Outstanding autonomy

The all-new KeyPad Plus firmware gets the most out of the pre-installed batteries. Even with daily use of the contactless identification function, the keypad will work for 3.5 years without replacing batteries. And with the card and key fob reader disabled, the battery life reaches 4.5 years. KeyPad Plus will warn a monitoring station and users in advance about the need to replace the batteries.

Remote access control

Set up personal codes to know who and when disarmed the system: a username is displayed in the notification and in the event log. Pass or Tag can also be assigned to a specific user with defined permissions to control security of specific groups or the entire site. Ajax app allows you to manage access permissions in real time. You can limit, extend, or instantly block access.

Adding users. Fast and easy.

Ajax systems support up to 200 Tag key fobs or Pass cards2. When adding them, you do not need to create Ajax accounts for new users, you just need to name a device and define access permissions. This makes it easier to delegate access to the system control to temporary employees or incoming staff.

Access for unregistered users

KeyPad Plus supports up to 99 keypad access codes for people not registered in the Ajax system. Thanks to this feature, there is no need to create accounts for office employees, a cleaning company, or a realtor: it is enough to assign an access code to a person in the hub settings.

Silent alarm transmission to a monitoring station

If attackers force to disarm the system

Duress code allows you to simulate disarming via KeyPad Plus. The user is not disclosed by sirens, the app and the keypad indication, but the alarm signal is instantly transmitted to a central monitoring station.

Guaranteed alarm delivery

We have developed the Jeweller radio protocol to ensure the uninterrupted operation of all system devices. The radio protocol uses time frames to synchronize communication of connected devices, authentication to eliminate spoofing, and encryption to protect against hacking.

Technical specifications

• Keypad type: Capacitive touch keypad
• Installation: Indoor only
• Compatibility: Hub Plus, Hub 2, Hub 2 Plus, Hub Hybrid, radio signal range extenders with OS Malevich 2.11 and higher
• Personal codes: Yes
• Protection against code guessing: Yes
• Duress code: Yes
• Contactless access: DESFire® EV1, EV2 ISO14443-А (13,56MHz)
• Power supply: Batteries: 4 lithium AA (FR6); Voltage 1.5V
• Battery life: up to 4.5 years
• Temperature sensor: Yes
• Jeweller radio technology: Communication range with control panel — up to 1,700 m; Two-way communication between devices
• Anti-sabotage: Authentification; Jamming detection; Tamper alarm
• Operating temperature range: From –10°C to +40°C
• Operating humidity: Up to 75%
• Dimensions: 165 × 113 × 20 mm
• Weight: 267 g
• Certification: EN 50131, complies with the requirements of the technical regulations for radio equipment
