Switch PFS3103-1GT1ET-60Dahua 2 PoE, SFP 1 port, 2 port HiPoE

Computer Network

Product reference: KSPFS3103-1GT1ET-60

Switch PFS3103-1GT1ET-60 Dahua 2 PoE, SFP 1 port, 2 port HiPoE

At stores prices may vary

Price:

€131.89

€109.00 tax excl.

Favourite

In manufacturer warehouse
Ask

Product information

Switch PFS3103-1GT1ET-60 Dahua 2 PoE, SFP 1 port, 2 port HiPoE

DH-PFS3103-1GT1ET-60 – 3-Port Unmanaged Hardened PoE Switch

Overview:
The DH-PFS3103-1GT1ET-60 is an unmanaged, hardened desktop PoE switch featuring:

1 × 10/100 Mbps PoE port
1 × 10/100 Mbps Ethernet port
1 × 1000 Mbps SFP port
1 × 10/100/1000 Mbps uplink port

It supports two transmission modes (Extend Mode On/Off) and includes an orange port compliant with IEEE802.3bt and Hi-PoE, delivering up to 60 W of power. The switch also supports a PoE Watchdog feature that automatically recovers failed ports, reducing manual maintenance.

Key Features:

Intelligent PoE
Provides real-time power monitoring and allocation, prioritizing critical ports and adapting to device power fluctuations, ensuring stable performance.

Hi-PoE 60W (Orange Port)
In addition to IEEE802.3af/at standards, the orange port supports up to 60W output for high-power devices like PTZ cameras.

PoE Watchdog
Enables automatic port recovery in case of connection issues, eliminating the need for manual restarts.

Long Distance PoE (up to 250 m)
With long-range mode enabled, PoE transmission distance can reach up to 250 meters (bandwidth reduced to 10 Mbps).

8-pin Assignment PoE Power Supply
Delivers power through both signal and idle wires (1/2/4/5 positive, 3/6/7/8 negative), enhancing compatibility, reducing cable loss, and increasing load capacity.

Application Scenarios:
Ideal for deployment in homes, offices, server rooms, small retail stores, and more.

Hardware

Data Transmission Port

Port 3: 1 × RJ-45 10/100M (PoE)
Port 2: 1 × RJ-45 10/100/1000M (PoE)
Port 1: 1 × SFP 100/1000M (uplink)

Power Supply

48 V - 57 V DC

Operaing Temperature

–30 °C to +65 °C (-22 °F to +149 °F)

Operating Humidity

5% – 95% (RH)

Power Consumption

Idling: 3 W
Full load: 60 W

Performance

Capacity

7.6 Gbps

Packet Forwarding Rate

4.17 Mbps

Packet Buffer Memory

1 Mbit

MAC Table Size

Communication Standard

IEEE802.3/IEEE802.3u/IEEE802.3X/IEEE 802.3ab/IEEE 802.3z

PoE

PoE Standard

IEEE802.3af/ IEEE802.3at/ Hi-PoE/ IEEE802.3bt

PoE Power

Port 2-3 ≤ 60 W (Hi-PoE), total≤ 60 W

Power Consumption Management

Yes

PoE Pin Assignment

1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)

Long Distance PoE

250 m (820.21 ft) long distance PoE transmission

General

Statics Protection

Air discharge: 8 kV
Contact discharge: 6 kV

Thunder-proof

Common mode: 4 kV
Differential mode: 2 kV

Net Weight

0.28 kg (0.62 lb)

Product Dimensions

105 mm × 75 mm × 30 mm (4.13" × 2.95" × 1.18")

Transmission Performance:
Switch power supply voltage 53V. CAT5E/CAT6. Max. DC resistance < 10 Ω/100 m
Cable(m)	Load Capacity(W)	Bandwidth(Mbps)
IEEE802.3bt 90 W
100	71.3	1000
150	62	10
200	51	10
250	40	10
Hi-PoE 60 W
100	53	1000
150	50	10
200	47	10
250	37	10
IEEE802.3at 30 W
100	25.5	1000
150	25.5	10
200	25.5	10
250	25.5	10

Features

Incoming Bandwidth	10/100/1000
Incoming Bandwidth	10/100
SFP ports	1 SFP

Manufacturer

Dahua Technology is a world-leading video-centric AIoT solution and service provider. With its ‘Dahua Think#’ corporate strategy, Dahua Technology focuses on two core businesses: City and Enterprise. The company firmly strengthens its technological strategies that include AloT and IoT digital intelligence platforms, comprehensively promoting the digital intelligence upgrading of cities and enterprises based on customer needs, and creating more value for the digital-intelligent transformation of various industries.
