Switch CS4226-24ET-375, 24PoE+2G upl, L2 man Dahua

Computer Network

Product reference: KSCS4226-24ET-375

> 24 × 10/100 Mbps PoE Ports, 2 × Gigabit combo ports.

> 375 W total PoE budget, 802.3af/at on all PoE port, additional 802.3bt on Red port.

> DIP switch to fast turn ON/OFF working mode of Cloud-Managed, PoE Watchdog, 250 Meter Long Distance PoE.

> –10°C to 55°C wide working temperature.

> VLAN, Loop protection.

> WEB-managed and centralized cloud management through the DoLynk app and performs real-time monitoring of the network.

> Easy config to auto detect and set up network and security systems.

At stores prices may vary

Price:

€301.29

€249.00 tax excl.

Favourite

We have 1 qty.
Delivery in 1-2 business days

Product information

Switch CS4226-24ET-375, 24PoE+2G upl, L2 man Dahua

26-Port Cloud Managed Desktop Switch with 24-Port PoE

Category	Specification
Layer	Layer 2
Switching Capacity	8.8 Gbps
Packet Forwarding Rate	6.55 Mpps
Ports	Port 1–24: 24 × RJ45 10/100 Mbps (PoE) Port 25–26: 2 × RJ45 10/100/1000 Mbps (Combo) Port 25–26: 2 × SFP 1000 Mbps (Combo)
Operating Temperature	–10 °C to +55 °C
Operating Humidity	10%–90% (non-condensing)
Storage Temperature	–40 °C to +70 °C
Storage Humidity	5%–95% (non-condensing)
Power Supply	Built-in: 100–240 VAC, 47–63 Hz, max 7 A
Power Consumption	Idle: 3 W; Full load: 382.5 W
Static Protection	Air discharge: 8 kV Contact discharge: 6 kV
Lightning Protection	Common mode: 6 kV Differential mode: 1 kV
Net Weight	2.7 kg
Gross Weight	3.5 kg
Product Dimensions	440 × 228.81 × 43.65 mm
Packaging Dimensions	540 × 342 × 90 mm
Casing Material	Sheet metal
Installation	Desktop; Rack mount
Certifications	CE
PoE Support	Yes
PoE Power	Ports 5–24 ≤ 30 W Ports 1–4 ≤ 90 W Total ≤ 375 W
PoE Protocols	IEEE 802.3af; IEEE 802.3at; Hi-PoE; IEEE 802.3bt
PoE Power Management	Power consumption management PoE on/off PoE shutdown on overload
PoE Pin Assignment	Ports 1–4: 1,2,4,5 (V+), 3,6,7,8 (V-) Ports 5–24: 1,2 (V+), 3,6 (V-)
Long Distance PoE	Yes (up to 250 m)
DIP Switch	Managed Mode: On by default PoE Watchdog: Auto restart if no traffic Extend Mode: Up to 250 m at 10 Mbps (Unmanaged mode only)
Reset Button	1
MTBF	1,298,465 h
Packet Buffer	4 Mbit
Jumbo Frame	9216 Byte
MAC Table	8K
Communication Standards	IEEE 802.3, 802.3u, 802.3X, 802.3ab, 802.3z, 802.3az
VLAN Count	32
VLAN Function	IEEE 802.1Q VLAN
Port Features	IEEE 802.3x Flow Control Unknown Unicast Suppression Multicast Storm Control Broadcast Storm Control MAC+Port Binding Loop Prevention
Mirroring	Local port mirroring; N:1 mirroring
Management	Web management Cloud management Logs Fault alarm
Packing List	User manual, Legal info, Power cord, Rack kit
