Switch CS4010-8ET2GT-110, 8x100Mbps, 2x1000Mbps, PoE 110W

Computer Network

Product reference: KSCS4010-8ET2GT-110

> 8 × RJ-45 10/100 Mbps PoE ports, 2 x RJ-45 Gigabit ports.

> 110 W total PoE budget, 802.3af/at on all PoE ports, additional 802.3 bt on red ports.

> DIP switch to fast turn on/off working mode of Cloud-Managed, PoE Watchdog, Long Distance PoE.

> Wide operating temperature ranging from –10 °C to 55 °C.

> Supports VLAN and loop protection.

> WEB-managed and centralized cloud management through the DoLynk App and performs real-time monitoring of the network.

> Easy config to auto detect and set up network and security systems.

At stores prices may vary

Price:

€113.74

€94.00 tax excl.

Favourite

We have 100+ qty.
Delivery in 1-2 business days

Product information

Switch CS4010-8ET2GT-110, 8x100Mbps, 2x1000Mbps, PoE 110W

Specification	Value
Switching Capacity	5.6 Gbps
Packet Forwarding Rate	4.17 Mpps
Description of Function Slots	Port 1-8: 8 × RJ-45 10/100 Mbps (PoE) Port 9-10: 2 × RJ-45 10/100/1000 Mbps (uplink)
Operating Temperature	–10 °C to +55 °C (+14 °F to +131 °F)
Operating Humidity	10%–90% (RH), non-condensing
Storage Temperature	–40 °C to +70 °C (–40 °F to +158 °F)
Storage Humidity	5%–95% (RH), non-condensing
Power Supply	External Power Adapter (54 V, 2.22 A)
Power Consumption	Idling: 5.7 W Full load: 115 W
Static Protection	Air discharge: 8 kV Contact discharge: 6 kV
Lightning Protection	Common mode: 6 kV Differential mode: 1 kV
Net Weight	0.36 kg (0.79 lb)
Gross Weight	1.09 kg (2.03 lb)
Product Dimensions	184.6 mm × 103.3 mm × 27 mm (7.27" × 4.07" × 1.06")
Packaging Dimensions	252 mm × 137 mm × 113 mm (9.92" × 5.39" × 4.45")
Casing Material	Sheet metal
Installation	Desktop mount; wall mount
Certifications	CE
PoE	Yes
PoE Power	Port 3-8 ≤30 W, port 1-2 ≤90 W, total ≤110 W
PoE Protocol	IEEE 802.3af; IEEE 802.3at; Hi-PoE; IEEE 802.3bt
PoE Power Consumption Management	PoE power consumption management; PoE power on/off; turns off PoE if overload is detected
PoE Pin Assignment	Port 1-2: 1,2,4,5 (V+), 3,6,7,8 (V-) Port 3-8: 1,2 (V+), 3,6 (V-)
Long Distance PoE Transmission	Yes
Hardware – DIP Switch	Managed Mode: On by default for both local web and cloud management. Off for Unmanaged Mode. PoE Watchdog: Monitors ports 1-8 and auto-restarts the PoE port when there is no traffic for 2 min. (Only works when Managed Mode is Off) Extend Mode: Ports 1-8; transmission distance up to 250 meters at 10 Mbps. (Only works when Managed Mode is Off)
Reset Button	1
MTBF	3,359,638 hours
Packet Buffer Size	4 Mbit
Jumbo Frame	9216 Byte
MAC Table Size	8K
Communication Standard	IEEE 802.3; IEEE 802.3u; IEEE 802.3x; IEEE 802.3ab; IEEE 802.3az
VLAN Number	32
VLAN Function	IEEE 802.1Q VLAN
Port Feature	IEEE 802.3x Flow Control; Unknown Unicast Suppression; Multicast Storm Control; Broadcast Storm Control; MAC+Port Binding; Loop Prevention; Mirror
Reliability	LLDP; DHCP Client
Security	Port Isolation
Equipment Management	Web Management; Cloud Management; Logs; Fault Alarm
Packing List	1 × User Manual; 1 × Legal and Regulatory Information; 1 × Power Cord; 1 × Power Adapter
Transmission Performance	Switch power supply voltage 54V; CAT6; Max. DC resistance < 8 Ω/100 m

Features

Incoming Bandwidth	10/100/1000
Incoming Bandwidth	10/100
SFP ports	Nėra
Ports	10
PoE ports	8
