ICS1-W2(868) Smart Plug

Dahua Accessories

Product reference: BSICS1-W2(868)

The Smart Plug is a highly intuitive power switch. It can be remotely controlled through the mobile app, scheduled to turn on and off, and set to activate automatically when alarms are triggered or the system is armed or disarmed.

At stores prices may vary

Price:

€60.11

€49.68 tax excl.

Favourite

Product information

ICS1-W2(868) Smart Plug suitable for scenes where remote control, electrical safety and energy efficiency are prioritized such as houses, stores and office buildings.

Two-way RF communication.
Displays the status with an LED indicator.
Supports cloud update and auto recovery after an update fails.
Offers protection against overcurrent, overvoltage, and overheating.
Measure the voltage, current and temperature.
Generates power consumption statistics and it can be reset to clear the statistics.
Output control mode can be selected between bistable and pulse modes.

Specifications

Port

Relay Output

1 port, NO/NC (100–240 VAC, max 16 A)

Wireless

Indicator Light

1 indicator light, displays multiple status
Flash green: paring
Solid green: the circuit is closed
Light off: the circuit is open

Remote Update

Supports cloud update

Button

1 button, perform multiple operations (open/close the circuit, restore to the factory settings and pair)

Signal Strength

Supports detecting signal strength.

Frequency Range

868-868.6 MHz

Communication Distance

In an open environment: 1,600 m (5249.34 ft)

MAX Power

865-868.6 MHz@16.15 dBm

Communication Mechanism

Two-way communication.

Encryption

AES-128

Frequency Hopping

Yes

General

Operating Temperature

Indoor: –10 °C to +55 °C (+14 °F to +131 °F)

Operating Humidity

10%–90%(RH), non-condensing

Storage Temperature

–10 °C to +55 °C (+14 °F to +131 °F)

Storage Humidity

10%–90%(RH), non-condensing

Power Supply

100–240 VAC, 50/60 Hz

Product Dimensions

52 mm × 52 mm × 82 mm (2.05" × 2.05" × 8.32") (L × W × H)

Installation

With power strip/2 Pin

Net Weight

83 g (0.18 lb)

Power Consumption

0.3 W

Certifications

Casing Material

Data Monitoring

Yes

Data Type

Current; voltage; temperature

Accuracy

Current Measurement Accuracy

Protection range: 0 A–16 A
Measurement Accuracy: level 1.0 and above.

Voltage Measurement Accuracy

Protection range: 0 V –250 V
Measurement Accuracy: level 1.0 and above.

Internal Temperature Monitoring Accuracy

Protection range: 0°C –55 °C
Measurement Accuracy: ±2% or ±2 °C

Alarm

Alarm Type

Alarm for overcurrent, overvoltage, and overheating
