Network Video Recorder NVR2108-4KS3 Dahua

Dahua cameras and NVRs

Product reference: MUNVR2108-4KS3

> Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG decoding formats.

> Max. decoding capability: 6 × 1080p@30 fps.

> Max. 80/80/60 Mbps incoming/recording/outgoing bandwidth.

> Supports IP cameras with a resolution up to 12 MP.

> AI by Recorder supports 4-channel SMD.

> AI by Camera supports perimeter protection and SMD.

> Supports one-click arming and disarming.

At stores prices may vary

Price:

€125.84

€104.00 tax excl.

Favourite

In manufacturer warehouse
Ask

Product information

Network Video Recorder NVR2108-4KS3 Dahua

Dahua DHI-NVR2108-4KS3 – 8-Channel Lite Network Video Recorder with AI Features

The Dahua DHI-NVR2108-4KS3 is an 8-channel Lite Series Network Video Recorder (NVR) that offers an excellent balance between performance, functionality, and affordability. Supporting 4K video resolution, it is ideal for surveillance applications where highly detailed images are required.

The recorder can operate as an edge, central, or backup storage device and features an intuitive interface for convenient local and remote management. With built-in AI capabilities, it significantly reduces false alarms and improves the overall efficiency of the surveillance system.

Easy installation and competitive pricing make it an excellent choice for homes, villas, retail stores, offices, and other small to medium-sized surveillance projects.

Key Features

Supports Smart H.265+, H.265, Smart H.264+, H.264 and MJPEG video compression.
Decodes up to 6 × 1080p @ 30 fps simultaneously.
Up to 80 Mbps incoming, 80 Mbps recording, and 60 Mbps outgoing bandwidth.
Supports IP cameras with resolutions up to 12 MP.
Recorder-based AI supports 4-channel Smart Motion Detection (SMD).
Camera-based AI supports Perimeter Protection and Smart Motion Detection (SMD).
One-click Arming/Disarming for quick system control.

SMD Plus

Powered by intelligent AI algorithms, Dahua Smart Motion Detection (SMD Plus) accurately distinguishes humans and vehicles from irrelevant motion events. This greatly reduces false alarms caused by environmental factors while ensuring more reliable event detection.

Perimeter Protection

When used with AI-enabled cameras, the system automatically filters false alarms triggered by animals, moving leaves, changing lighting conditions, and similar disturbances. Advanced target recognition improves alarm accuracy and enhances the effectiveness of the overall surveillance system.

System

Main Processor

Industrial-grade processor

Operating System

Embedded Linux

Operating Interface

Web, Local GUI

AI by Recorder

SMD

AI by Camera

Perimeter protection; SMD

Perimeter Protection

Perimeter Performance of AI by Camera (Number of Channels)

All channels (4 targets/s)

SMD Plus

SMD Plus by Recorder

4 channels: Secondary filtering for human and motor vehicle, reducing false alarms caused by leaves, rain and lighting condition change

SMD Plus by Camera

All channels (8 targets/s)

Audio and Video

Access Channel

8 channels

Network Bandwidth

80 Mbps incoming, 80 Mbps recording and 60 Mbps outgoing

Resolution

12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF;QCIF

Decoding Capability

AI disabled: 1-channel 12 MP@30 fps; 1-channel 8 MP@30 fps; 2-channel 6 MP@30 fps; 2-channel 5 MP@30 fps; 3-channel 4 MP@30 fps; 6-channel 1080p@30 fps

AI enabled: 1-channel 8 MP@30 fps; 1-channel 6 MP@30 fps; 1-channel 5 MP@30 fps; 2-channel 4 MP@30 fps; 4-channel 1080p@30 fps

Video Output

1 HDMI, 1 VGA

HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720

VGA: 1920 × 1080, 1280 × 1024, 1280 × 720

Multi-screen Display

1/4/8/9

Third-party Camera Access

ONVIF

Compression Standard

Video Compression

Smart H.265+; H.265; Smart H.264+; H.264; MJPEG

Audio Compression

G.711a; G.711u; PCM; G726;

Network

Network Protocol

HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; IP Filter; DDNS; IP Search (Supports IP camera, DVR, NVS, etc.); P2P; Auto Registration

Mobile Phone Access

iOS; Android

Interoperability

ONVIF 23.12(Profile T; Profile S; Profile G); CGI; SDK

Browser

Chrome; IE; Safari; Edge; Firefox

Recording Playback

Multi-channel Playback

Up to 8 channels

Record Mode

General, motion detection; intelligent; alarm

Backup Method

USB device and network

Playback Mode

Instant playback; general playback; event playback; tag playback; smart playback

Alarm

General Alarm

Motion detection; camera external alarm; PIR alarm

Anomaly Alarm

Error (no disk, disk error, low space, low quota space; network disconnection; IP conflict; MAC conflict); video loss; video tampering; camera offline

Intelligent Alarm

Perimeter protection; SMD Plus

Alarm Linkage

Recording; snapshot; buzzer; log; preset; email; tour

Port

Audio Input

1-channel RCA

Audio Output

1-channel RCA

Alarm Input

NA (2 channels are optional)

Alarm Output

NA (1-channel 12 V 1 A output is optional)

Disk Interface

1 SATA port. Each disk can contain up to 20 TB. this limit varies depending on the environment temperature.

USB

2 (2 rear USB 2.0 ports)

HDMI

VGA

Network Port

1 (10/100 Mbps Ethernet port, RJ-45)

General

Power Supply

12 VDC, 1.5 A

Power Consumption

<10 W (without HDD)

Net Weight

0.45 kg (0.99 lb)

Gross Weight

1.05 kg (2.31 lb)

Product Dimensions

204.6 mm × 206.4 mm × 45.6 mm(8.06" × 8.12" × 1.80") (W × D × H)

Packaging Dimensions

364.0 mm × 96.0 mm × 261.0 mm(14.33" × 3.78" × 10.28")(W × D × H)

Operating Temperature

–10 °C to +55 °C (14 °F to +131 °F)

Storage Temperature

–20 °C to +60 °C (–4 °F to +140 °F)

Operating Humidity

10%–93% (RH), non-condensing

Certifications

CE-LVD: IEC 62368-1:2014

CE-EMC: EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 55032:2015+A11:2020, EN 55035:2017+A11:2020, EN 55024:2010+A1:2015, EN 50130-4:2011+A1:2014

Features

Chanels	8
Product class	LITE
Internal HDD	1 HDD
Incoming Bandwidth	8 Mbps

Manufacturer

Dahua Technology is a world-leading video-centric AIoT solution and service provider. With its ‘Dahua Think#’ corporate strategy, Dahua Technology focuses on two core businesses: City and Enterprise. The company firmly strengthens its technological strategies that include AloT and IoT digital intelligence platforms, comprehensively promoting the digital intelligence upgrading of cities and enterprises based on customer needs, and creating more value for the digital-intelligent transformation of various industries.
