TP-Link Switch 28 port 1000M PoE+Omada SG3428MP

Omada Wireless System

Product reference: KSSG3428MP

24× Gigabit 802.3af/at PoE+ ports and 4× Gigabit SFP slots
384 W total PoE budget with up to 30 W PoE output per port*
Centralized cloud management via the web or the Omada app^†
Standalone management via web, CLI, SNMP, and RMON
Static Routing helps route internal traffic for higher efficiency
VLAN, ACL, QoS, IGMP Snooping, OAM, and DDM
ERPS supports rapid protection and recovery in a ring topology
Durable metal casing and rack-mountable design

At stores prices may vary

Price:

€403.54

€333.50 tax excl.

Favourite

In manufacturer warehouse
Ask

Product information

TP-Link Switch 28 port 1000M PoE+Omada SG3428MP

Category	Feature	Description
Hardware Features	Interface	24× 10/100/1000 Mbps RJ45 PoE+ Ports 4× Gigabit SFP Slots 1× RJ45 Console Port 1× Micro-USB Console Port
	Fan Quantity	2
	Physical Security Lock	Yes
	Power Supply	100-240 V AC~50/60 Hz
	PoE Ports (RJ45)	Standard: 802.3af/at compliant PoE+ Ports: 24 Ports (up to 30 W PoE Output per Port) Power Budget: 384 W*
	Dimensions (W x D x H)	17.3×13.0×1.7 in (440×330×44 mm)
	Mounting	Rack Mountable
	Max. Power Consumption	480.1 W (110 V/60 Hz, with 384 W PD connected)
Performance	Switching Capacity	56 Gbps
	Packet Forwarding Rate	41.66 Mpps
	MAC Address Table	16K
	Packet Buffer Memory	12 Mbit
	Jumbo Frame	9 KB
Software Features	Quality of Service (QoS)	8 priority queues 802.1p CoS/DSCP priority Queue scheduling: SP, WRR, SP+WRR Bandwidth Control: Port/Flow based rating limiting Action for Flows: QoS remark (802.1P Remark, DSCP Remark)
	L2 and L2+ Features	128 IP Interfaces: IPv4/IPv6 support Static Routing: 48 IPv4/IPv6 static routes Static ARP: 128 entries 512 ARP entries Proxy ARP, Gratuitous ARP DHCP Server, DHCP Relay, DHCP L2 Relay Link Aggregation, Spanning Tree Protocol, Loopback Detection 802.3x Flow Control, Mirroring, DLDP
	L2 Multicast	Supports 511 IGMP groups (IPv4, IPv6) IGMP Snooping, IGMP Authentication Multicast VLAN Registration (MVR), MLD Snooping Multicast Filtering: 256 profiles, 16 entries per profile
	Advanced Features	Automatic Device Discovery† Batch Configuration† Batch Firmware Upgrading† Intelligent Network Monitoring† Abnormal Event Warnings† Unified Configuration† Reboot Schedule†
	ISP Features	L2PT (Layer 2 Protocol Tunneling) DLDP PPPoE ID Insertion ERPS 802.3ah Ethernet Link OAM DDM, sFlow
VLAN	VLAN Group	Max 4K VLAN Groups, 802.1q Tagged VLAN MAC VLAN: 30 entries Protocol VLAN: Protocol Template 16, Protocol VLAN 16 Private VLAN, GVRP, VLAN VPN (QinQ), Voice VLAN
	Access Control List (ACL)	Time-based ACL MAC ACL: Source/Destination MAC, VLAN ID, User Priority, Ether Type IP ACL: Source/Destination IP, Fragment, Protocol, TCP Flag, TCP/UDP Port, DSCP/IP TOS, User Priority Combined ACL, Packet Content ACL, IPv6 ACL Policy: Mirroring, Redirect, Rate Limit, QoS Remark ACL applies to Port/VLAN
	Security	IP-MAC-Port Binding (512 entries), DHCP Snooping, ARP Inspection, IPv4/IPv6 Source Guard DoS Defend, DHCP Filter Static/Dynamic Port Security (up to 64 MAC per port) Broadcast/Multicast/Unicast Storm Control 802.1X, AAA (TACACS+), Port Isolation Secure Web Management (HTTPS), Secure CLI (SSHv1/SSHv2)
	IPv6	Dual IPv4/IPv6 MLD Snooping, IPv6 ACL, Static IPv6 Routing ND Detection, MTU Discovery ICMPv6, TCPv6/UDPv6 IPv6 Applications: DHCPv6 Client, Ping6, Tracert6, Telnet v6, SNMP v6, SSH v6, SSL v6, Http/HTTPS, IPv6 TFTP
MIBs	Supported MIBs	MIB II (RFC1213), Bridge MIB (RFC1493), P/Q-Bridge MIB (RFC2674) Radius Accounting/Authentication Client MIB Remote Ping, Traceroute MIB (RFC2925) TP-Link private MIBs, RMON MIB (RFC1757, groups 1,2,3,9)
Management Features	Omada App	Requires Omada Hardware, Cloud-Based, or Software Controller
	Centralized Management	Omada Cloud-Based Controller, Hardware Controller, Software Controller
	Cloud Access	Yes, requires Omada Controller
	Zero-Touch Provisioning	Yes, requires Omada Cloud-Based Controller
	Other Management	Web GUI, CLI via console/telnet, SNMPv1/v2c/v3, RMON groups 1,2,3,9 SDM Template, DHCP/BOOTP Client, LLDP/LLDP-MED, DHCP AutoInstall Dual Image/Dual Configuration, CPU Monitoring, Cable Diagnostics, EEE, SNTP, Password Recovery, System Log
Others	Certification	CE, FCC, RoHS
	Package Content	SG3428MP Switch, Power Cord, Quick Installation Guide, Rackmount Kit, Rubber Feet
	System Requirements & Environment	Windows 98SE/NT/2000/XP/Vista/7/8/10/11, MAC OS, NetWare, UNIX, Linux Operating Temperature: 0–45 ℃ (32–113 ℉) Storage Temperature: -40–70 ℃ (-40–158 ℉) Operating Humidity: 10–90% RH non-condensing Storage Humidity: 5–90% RH non-condensing

Features

Ports	28
PoE+ ports	24
Gigabit	Yes
