Dahua Switch CS4218-16ET-240, 16x10/100 PoE, 2x Combo, L2, 240W

Switches

Product reference: KSCS4218-16ET-240

> 16 × 10/100 Mbps PoE Ports, 2 × Gigabit combo ports.

> 240 W total PoE budget, 802.3af/at on all PoE port, additional 802.3bt on Red port.

> DIP switch to fast turn ON/OFF working mode of Cloud-Managed, PoE Watchdog, 250 Meter Long Distance PoE.

> –10°C to 55°C wide working temperature. VLAN, Loop protection.

> WEB-managed and centralized cloud management through the DoLynk app and performs real-time monitoring of the network.

> Easy config to auto detect and set up network and security systems.

At stores prices may vary

Price:

€308.55

€255.00 tax excl.

Favourite

We have 2 qty.
Delivery in 1-2 business days

Product information

Dahua Switch CS4218-16ET-240, 16x10/100 PoE, 2x Combo, L2, 240W

System Overview

The Cloud Managed Switch offers highly intuitive local network management. With the DoLynk Cloud-Management platform, it additionally enables seamless cloud management capabilities. Using EasyConfig, both CCTV and IT systems can be deployed with just one click.

The switch supports operation and maintenance through topology visualization of front-end devices, transmission systems, and backend storage devices. Managed mode can be easily turned on or off using a physical switch. The device also supports advanced PoE 2.0 features.

Its full-metal housing provides excellent heat dissipation and stable operation in temperatures ranging from –10 °C to +55 °C. The switch also features up to 6 kV surge protection against static electricity, lightning, and pulse interference.

Ideal for small and medium-sized businesses such as supermarkets, offices, restaurants, cafés, and hotels.

Application

Suitable for environments such as factories, office buildings, and commercial facilities.

Features

Managed Mode ON/OFF

Quickly switch between managed and unmanaged modes with a simple switch. In managed mode, the switch can be managed locally through a webpage or remotely through the cloud platform.

Network Topology Management

Supports the LLDP protocol and automatically generates network topology maps, helping quickly identify issues and remotely maintain connected devices.

BT 90W (Red Port)

The red ports support IEEE802.3af, IEEE802.3at, IEEE802.3bt, and Hi-PoE standards with up to 90W output per port, making them suitable for high-power devices.

Long Distance PoE

PoE transmission distance can reach up to 250 meters, suitable for long-range wired deployments (bandwidth reduced to 10 Mbps).

PoE Watchdog

The innovative PoE Watchdog automatically detects port failures and restarts malfunctioning ports to restore IPC camera connections, reducing manual maintenance costs and improving system reliability.

Loop Protection

When a network loop is detected, the switch triggers an alarm and automatically activates protection mechanisms to prevent broadcast storms.

Cloud Management

Devices can be managed through the DoLynk Care app, which provides real-time network monitoring, device status visualization, instant fault alarms, and notifications.

Basic
Layer	Layer 2
Switching Capacity	7.2 Gbps
Packet Forwarding Rate	5.36 Mpps
Ports	Port 1-16: 16 × RJ45 10/100 Mbps (PoE) Port 17-18: 2 × RJ45 10/100/1000 Mbps (Combo) Port 17-18: 2 × SFP 1000 Mbps (Combo)
Operating Temperature	–10 °C to +55 °C
Operating Humidity	10%–90% RH, non-condensing
Storage Temperature	–40 °C to +70 °C
Storage Humidity	5%–95% RH, non-condensing
Power Supply	Built-in power supply: 100–240 VAC, 47–63 Hz, max 4 A
Power Consumption	Idling: 3 W Full load: 246.8 W
Static Protection	Air discharge: 8 kV Contact discharge: 6 kV
Lightning Protection	Common mode: 6 kV Differential mode: 1 kV
Net Weight	2.5 kg
Gross Weight	3.2 kg
Product Dimensions	440 × 228.81 × 43.65 mm
Packaging Dimensions	540 × 342 × 90 mm
Casing Material	Sheet metal
Installation	Desktop mount; rack mount
Certifications	CE

Features

Incoming Bandwidth	10/100
Incoming Bandwidth	10/100/1000
SFP ports	2 SFP
Ports	18
PoE ports	16
