Atom 6U Neon Smart Home Controller 12in/12out

Контроллеры

Код товара: EP6UAtomNeon

Atom 6U Neon Smart Home Controller. The name itself says that its main purpose is to control modern lighting devices such as LED strips, furniture lamps, low-voltage LED lamps and more.

Читать подробнее

Цена в физическом магазине может отличаться

Цена:

785,29 €

649,00 € без НДС

Сохранить

In manufacturer warehouse
Спросите

Информация о товаре

Atom 6U Neon Features:

CAN bus ensures synchronized operation of all Atom series devices.
Integrate 3rd party devices using RS-485 interface.
5V and 3.3V ports for sensors power supply.
12 multifunction input ports for temperature, air quality, water leakage sensors and switches connection.
4 x 5A relays for connection of electrical devices.
8. 8 dimming outputs built on MOSFET bases with built-in load control meter to control DC.

Technical Specifications

Inputs
Input ports	12 digital (10 of them with a possibility to work in analog mode)
Voltage range for inputs without optocoupler mode / with optocoupler mode (selected with jumper)	0-3,3V / 0-5V
ADC bit rate for input ports in analog mode	12 bit
Outputs 1-8
DC switching voltage	0 - 48V
Max switching current	5A
Max inrush current	40A
Built-in current sensors to monitor load operation	✔
Dimming capabilities	PWM (up to 30KHz)
Outputs 9-12
Number of built-in normally opened relays / Active load	4 x 5А 250V AC/ 30V DC
Max inrush current	50А
Interfaces
CAN	✔
RS-485 (Modbus protocol)	✔
Digital interfaces on input ports	1 laidas
Ethernet 10/100 Mb	✖ (in Atom Neon N modification)
WiFi 802.11 b/g/n 2,4 GHz	✖ (in Atom Neon N modification)
Bluetooth v4.2 BLE	✖ (in Atom Neon N modification)
LoRa 868 MHz	✖ (in Atom Neon N modification)
Indication
Input and output ports status LEDs	✔
Ethernet port status LEDs	✖ (in Atom Neon N modification)

Power supply

Device power supply voltage (with protection against reverse polarity connection) 9 - 48V DC
Output voltage to power the sensors 3.3V (200mА), 5V (200mА)
Consumption (max) 15W

Other

Mounting type DIN rail (EN 60715)
Width, DIN units 6 DIN module
HxWxL 59 х 88 х 105 mm
Type of connectors / Recommended wire cross section inputs clamps / 0.2 - 1.5 mm²
Type of connectors / Recommended wire cross section outputs w/ screws, detachable/ 2,5 mm²

Atom Neon input’s specifications

Type of input / # of input	1-2	3-9	10-12
Analog (thermistor, photoresistor, etc.)	✖	✔	✔
Digital (motion sensors, light level sensors, switches, buttons, etc.)	✔	✔	✔
Interface (1-Wire sensors)	✔	✔	✔

Atom 6U comparison:

Atom 6U model	IN	OUT	QUANTITIES AND TYPES OF OUTPUTS
Atom 6U Hydrogen	12	10	2 relays, 8 ports, i3 flex	5A 250V/30V DC See "Changeable modules"
Atom 6U Ferrum	12	10	2 relays 8 relays	5A 250V/30V DC 10A 250V AC
Atom 6U Argon	12	18	18 relays	5A 250V/30V DC
Atom 6U Neon	12	12	4 relays 8 dim	5A 250V/30V DC 0-48V DC 5A
Atom 6U Oxygen	22	17	12 relays 5 dim	5A 250V/30V DC 180-250V AC/ 150W
